Number Items Technical Data
1 Max Layer Count 32 Layer
2 Max Board Size 640mm*1100mm
3 Board Thickness
2 Layer 0.2mm-6.0mm
4 Layer 0.4mm-8.0mm
6 Layer 0.8mm-8.0mm
8 Layer 1.0mm-8.0mm
10 Layer 1.2mm-8.0mm
12 Layer 1.5mm-8.0mm
14 Layer 1.5mm-8.0mm
16 Layer 1.6mm-8.0mm
18 Layer 2.2mm-8.0mm
20 Layer 2.4mm-8.0mm
4 Min Trace Width 3.0mil
5 Min Trace Space 3.0mil
6 Min Hole Size
Through Hole 0.15mm
Laser Via Hole 0.1mm
7 PTH Tolerance +/-0.075mm
8 NPTH Tolerance +/-0.05mm
9 Outline Tolerance +/-0.1mm
10 Hole Position Tolerance +/-0.05mm
11 Min Soldermask Bridge 0.075mm
12 Hole Wall Copper Thickness 10um-50um
13 Copper Thickness
InnerLayer 0.5oz-5oz
Outer Layer 0.5oz-13oz
14 Surface Finish HASL, OSP, Immersion Gold/Silver/Tin, Flash Gold, Golden Finger
15 Insulation Resistance 1*1012Ω
16 Aspect Ratio 13:1
17 Warp And Twist ≤0.7%
18 Impedance Control +/-10%
19 Flame Retardance 94V-0
20 Material FR4, High TG FR4, High Frequency Material, Aluminum
